Upgraded 61C

A 61C upgraded to 7.5. A "fork-lift" upgrade, as the installers move shelves and columns around. The Core/Net column has been replaced with an MG1010 cabinet. The IPE XPEC's are swapped for MG XPECs. The 50VDC power system is retained.
